18ga Speaker Wire Description
18/2 stranded bare copper conductors, unshielded with an overall jacket.
18ga Speaker Wire Details
Specifications
| Conductor | 18 AWG Bare Copper |
|---|---|
| Stranding | 7×26 |
| Insulation Material | PVC |
| Insulation Thickness | 0.008'' Nom. |
| Number of Conductors | 2 |
| Shield | None |
| Drain | None |
| Jacket Material | PVC |
| Jacket Thickness | 0.017'' Nom. |
| Overall Cable Diameter | 0.156'' Nom. |
| Approximate Cable Weight | 16.1 Lbs/1M' Nom. |
| Flame Rating UL | 1666 Riser Flame Test |
| Temperature Rating | -20°C To +60°C |
| Operating Voltage | 300 V RMS |
| Max.Capacitance Between Conductors @ 1 KHz | 30 pf/ftNom. |
| DC Resistance per Conductor @ 20deg C | 6.2 Ohms/1M'Nom. |
| Insulation Colors | Black ,Red |
| RoHS Compliant | Yes |
| Max. Recommended Pull Tension | 42 lbs. |
| Min. Bend Radius (Install) | 1.6" |
